Industrial Globe Valve - Cast Steel, Stainless Steel & Alloy Steel
Tengs Valve supplies high-quality Industrial Globe Valves in cast carbon steel, stainless steel, and alloy steel, manufactured to BS 1873, ASME B16.34, and DIN standards. Available with flanged or butt weld (BW) end connections. Size range from 2″ to 18″ (DN50 to DN450), with pressure ratings from 150LBS to 2500LBS and PN10 to PN100. Operated by handwheel, bevel gear, or bare stem. Ideal for oil & gas, chemical, power generation, and water treatment applications requiring reliable flow regulation and shut-off.
Industrial Globe Valve Standards
• Design and Manufacture: BS 1873, ASME B16.34
• Inspection and Test: API 598
• End Flange Dimension: ASME B16.5
• BW Ends Dimension: ASME B16.25
• Face to Face or End to End: ASME B16.10
• Pressure-Temperature Rating: ASME B16.34
✓ BS 1873 covers cast and forged carbon, alloy, and stainless steel OS&Y globe valves for the petroleum, petrochemical, and allied industries, sizes DN15 to DN400 (½″ to 16″), Classes 150 to 2500
Industrial Globe Valve Materials List
| Part Name | Carbon Steel (WCB) | Stainless Steel (CF8 / CF8M) | Alloy Steel (WC6 / WC9 / C5 / C12) |
|---|---|---|---|
| Body | A216 WCB | A351 CF8 / CF8M | A217 WC6 / WC9 / C5 / C12 |
| Bonnet | A216 WCB | A351 CF8 / CF8M | A217 WC6 / WC9 / C5 / C12 |
| Disc | WCB + 13Cr / STL | CF8 / CF8M | WC6 / WC9 + 13Cr / STL |
| Stem | A182 F6a / F304 / F316 | A182 F304 / F316 | A182 F6a / F304 / F316 |
| Seat | 13Cr / STL | SS304 / SS316 | 13Cr / STL |
| Packing | Graphite | Graphite | Graphite |
| Bolts / Nuts | A193 B7 / A194 2H | A193 B8 / A194 8, B8M / 8M | A193 B7 / A194 2H |
Reference: BS 1873, ASME B16.34, API 598. Materials may vary by model and pressure rating. Contact us for confirmed material certificate.
Globe Valve vs Gate Valve: Functional Comparison
| Feature | Globe Valve | Gate Valve |
|---|---|---|
| Primary Function | Throttling and flow regulation | On-off isolation only |
| Flow Path | S-shaped, higher pressure drop | Straight-through, minimal pressure drop |
| Disc Movement | Plug moves vertically along flow axis | Wedge moves perpendicular to flow |
| Sealing | Better throttling, tighter shut-off | Not suitable for throttling |
| Typical Application | Flow control, bypass, vent, drain | Main line isolation, on-off service |
Reference: BS 1873. Globe valves are designed for throttling and frequent operation; gate valves should only be used fully open or fully closed.
Typical Applications of Industrial Globe Valve
• Oil & gas transmission: crude oil, natural gas, and refined product pipelines requiring flow regulation and reliable shut-off.
• Refinery and petrochemical: process lines where precise throttling and frequent operation are required.
• Power generation: main steam, feedwater, and auxiliary systems at all pressure classes from 150LBS to 2500LBS.
• Chemical processing: corrosive media handling with CF8 / CF8M / alloy steel options.
• Water treatment: pump discharge, bypass, and flow control in water and wastewater systems.
• General industrial pipelines: non-corrosive and mildly corrosive media where flow regulation is needed.
FAQ - Industrial Globe Valve
Q1: What is an industrial globe valve?
A: An industrial globe valve is a linear motion valve designed for throttling and flow regulation in pipelines. It uses a movable plug or disc that moves along the flow axis to control flow rate. The name "globe" comes from the spherical body shape. It is manufactured to BS 1873 / ASME B16.34 and is available in pressure classes from 150LBS to 2500LBS and PN10 to PN100.
Q2: What is the difference between a globe valve and a gate valve?
A: A globe valve uses a plug that moves along the flow axis, providing better throttling and flow regulation — ideal for modulating service. A gate valve uses a wedge that moves perpendicular to the flow, providing full bore flow with minimal pressure drop — ideal for on-off isolation only. Globe valves should be used for throttling, while gate valves should only be used fully open or fully closed.
Q3: What is BS 1873 standard?
A: BS 1873 is a British Standard for "Specification for steel globe and globe stop and check valves (flanged and butt-welding ends) for the petroleum, petrochemical, and allied industries." It specifies requirements for cast or forged carbon and alloy steel outside screw and yoke globe valves, straight pattern, angle pattern, and Y pattern, in sizes DN15 to DN400 (½″ to 16″) and Classes 150 to 2500.
Q4: What materials are available for globe valves?
A: Common body materials include WCB, LCB, WC6, WC9, C5, C12, CF8, CF8M, CF3, CF3M, 4A, and 5A. Various trim materials such as 13Cr, STL, SS304, SS316, and F6a are available to suit different service conditions.
Q5: What end connections and actuation options are available?
A: End connections include flanged (RF, RTJ) and butt weld (BW). Actuation options include manual handwheel, bevel gear, and bare stem for electric actuator. Other options are available on request.
Q6: Is NACE MR 0175 available for globe valves?
A: Yes. NACE MR 0175 compliance is available on request for sour service applications. Please specify this requirement when requesting a quotation.
Get a Fast Quote for Industrial Globe Valve
Send us your size, pressure rating, material, end connection, actuation type, and quantity. Our team will reply within 24 hours with price, drawing, and delivery time.
Email: sales@tengsvalve.com
Website: Request a Quote Online
Email Us Now
Industrial Globe Valve Dimension Details
