Floating Ball Valve - API6D, Full Bore, 2-Piece / 3-Piece Split Body
Tengs Valve supplies high-quality Floating Ball Valves in full bore design, available in 2-piece and 3-piece split body configurations with side entry. The ball valves are made of cast or forged carbon steel and stainless steel, with flanged end connections, and are operated by lever or gearbox. Manufactured to API6D, ANSI, and DIN standards. Ideal for oil & gas, chemical, water treatment, and general industrial applications requiring reliable shut-off and low operating torque.
Floating Ball Valve Standards
• Design and Manufacture: API6D
• Inspection and Test: API 598, API 6D
• End Flange Dimension: ASME B16.5
• BW Ends Dimension: ASME B16.25
• Face to Face or End to End: ASME B16.10
• Pressure-Temperature Rating: ASME B16.34
Floating Ball Valve Materials List
| Part Name | Carbon Steel | Stainless Steel |
|---|---|---|
| Body | A216 WCB / A105 | A351 CF8 / CF8M / F304 / F316 |
| Ball | SS304 / 316 | SS304 / 316 |
| Stem | A182 F6a / 17-4PH | A182 F304 / F316 / 17-4PH |
| Seat | PTFE / RPTFE / Nylon | PTFE / RPTFE / PEEK |
| Gasket | Graphite / PTFE | Graphite / PTFE |
| Bolts/Nuts | A193 B7 / A194 2H | A193 B8 / A194 8, B8M / 8M |
Reference: API6D. Materials may vary by model and pressure rating. Contact us for confirmed material certificate.
Floating Ball Valve Dimension Details
